Heat pump for ACS with wifi Ferroli EGEA TECH HT of 260 liters

The Ferroli EGEA TECH HT 260 liters heat pump for ACS is an innovative and high-performance solution, ideal for warm climates. Designed for floor installation, it combines energy efficiency, sustainability, and advanced technology, providing domestic hot water consistently and economically.

High performance for warm climates

With an eco-friendly refrigerant R134A of low environmental impact (GWP 1,430), this heat pump is optimized to operate at air temperatures above 4 ºC. Its passive defrosting system ensures efficient operation without the need for electrical support, reaching a maximum hot water temperature of 62 ºC solely with the heat pump.

Highlighted efficiency parameters:

• SCOP under standard conditions (20 ºC): 3.1.
• SCOP in warm climate (14 ºC): 2.6.
• Annual energy consumption: 1,315 kWh (standard climate).
• Maximum hot water capacity at 40 ºC (standard climate): 358 liters.

Advanced technology and WiFi connectivity

The Ferroli EGEA TECH HT 260 L includes built-in WiFi connectivity, allowing control of the unit via a mobile app. This system facilitates weekly programming, consumption monitoring, and the use of the OFF PEAK function, which optimizes operation during lower energy cost hours.

Advanced features:

• Automatic anti-legionella program: Eliminates bacteria and ensures water hygiene.
• Energy monitoring system: Allows precise consumption control.
• Cascade control: Possibility to connect up to eight units for large installations.

Available operating modes:

• Auto: Automatic adjustment according to conditions.
• Eco: Prioritizes energy efficiency.
• Boost: Accelerates ACS production.
• Electric: Exclusive use of the electric resistance.
• Fan: Operation without ACS production.

Compact design and durability

With a diameter of 621 mm and a height of 1,892 mm, the EGEA TECH HT 260 L is designed to optimize available space, being suitable for rooms with a minimum volume of 20 m³. Its double magnesium anode system protects the tank against corrosion, prolonging the equipment's lifespan.

Design specifications:

• Weight: 98 kg, for greater stability in floor installation.
• Thermal dispersion of the tank: 70 W, for better heat retention.
• IP protection: IP-24, suitable for humid environments.

Compatibility with renewable energies

Ready to integrate with photovoltaic solar energy systems, this heat pump is a sustainable solution to reduce energy consumption and harness renewable sources.

Highlighted technical data

• Thermal power of the heat pump: 1,283 W.
• Support electric resistance: 1,500 W.
• Sound power: 52 dB(A), suitable for residential environments.
• Heating time under standard conditions (20 ºC): 9:44 hh:mm.
• Heating time in BOOST mode: 4:57 hh:mm.

Additional advantages

• Optimized production: ACS up to 62 ºC without the need for electric resistance.
• High capacity: Ideal for large families or higher ACS demands.
• Ease of installation and handling: Compatible with solar systems and advanced connectivity.

The Ferroli EGEA TECH HT 260 liters heat pump is an efficient, sustainable, and technologically advanced solution, designed to maximize comfort and reduce energy consumption in warm climates. Its robust design, WiFi connectivity, and compatibility with renewable energies make it an ideal choice for homes and large residential applications.
