The Baxi Platinum BC Plus Monobloc 2 12 TR is a three-phase outdoor aerothermal unit designed to provide heating, cooling, and domestic hot water with maximum efficiency and ease of installation. Thanks to its monobloc design, the entire refrigerant circuit is contained within the outdoor unit, eliminating the need for refrigerant connection and allowing installation via water ducts. This model includes a remote control for advanced and precise system management.
Main Features
- Monobloc system: No refrigerant connection required, simplifying installation.
- High performance: COP of up to 4.9 in heating and supply temperature of up to 65°C.
- Advanced control: Remote control included, allowing management of up to 2 circuits and cascade connection of up to 6 units.
- Maximum energy efficiency: SCOP of 4.81 and SEER of 7.07, optimizing consumption.
- Compact and quiet design: Single fan, with reduced noise levels.
- Optimized hydraulic connection: 1 1/4” inlet for easy installation.
- Quiet operation: Acoustic power of 65 dB(A).
Technical Specifications
- Heating power: 12.1 kW (35°C), 12.3 kW (45°C), 11.9 kW (55°C).
- SCOP: 4.81 in heating at 35°C.
- SEER: 7.07 in cooling at 18°C.
- Supply temperature: Maximum 65°C in heating, minimum 5°C in cooling.
- Expansion vessel capacity: 8 liters.
- Power supply voltage: 400V ~3 (three-phase).
- Maximum current: 14 A.
- Hydraulic connection: 1 1/4”.
- Refrigerant: R32 (1.75 kg).
- Empty weight: 160 kg.
The Baxi Platinum BC Plus Monobloc 2 12 TR is an efficient and compact solution for space climate control with three-phase supply, offering a design optimized for high performance and ease of installation. It includes a remote control for precise and versatile management.
