SILENT DUAL 200 Bathroom Extractor

The bathroom extractor Soler y Palau SILENT DUAL 200 is an innovative and efficient solution designed to ensure optimal ventilation in bathrooms and toilets without the need for manual interaction. Thanks to its advanced autonomous and intelligent control technology, this extractor automatically adjusts its ventilation performance according to the environmental conditions and the ventilation needs of the space in which it is installed.

The SILENT DUAL 200 is equipped with two key sensors: a presence detector and a humidity sensor, allowing it to operate completely autonomously. Through an intelligent algorithm, the extractor learns from the environmental conditions and determines when and how it should operate to maintain a healthy and moisture-free environment. This system ensures efficient and optimized operation without user intervention, contributing to significant energy savings.

The AC motor of the SILENT DUAL 200 is designed to adjust its speed and consumption based on the actual demand for ventilation. In its maximum mode, the extractor can reach a speed of 2280 rpm with an air flow of 170 m³/h, while in its continuous mode it maintains a flow of 60 m³/h at 1010 rpm, allowing for constant and discreet ventilation throughout the day. This flexibility ensures that the extractor operates only when necessary, minimizing noise and energy consumption.

This model features an IP45 protection, making it resistant to dust and water splashes, ideal for humid environments like bathrooms. It is also equipped with a removable backdraft damper, which prevents outside air or unwanted odors from entering the room when the extractor is not in operation.

The SILENT DUAL 200 has a maximum noise level of 34 dB(A), making it one of the quietest extractors in its category. Additionally, its compact and elegant design in white allows it to easily integrate into any bathroom. It is suitable for installation in ducts with a 118 mm diameter and has a wall entry diameter of 125 mm.

Technical specifications:

• Model: SILENT DUAL 200
• Reference: 5210641000
• Type of fan: Autonomous bathroom extractor
• Maximum/continuous power: 17W / 7W
• Maximum/continuous speed: 2280 rpm / 1010 rpm
• Maximum/continuous flow: 170 m³/h / 60 m³/h
• Power supply voltage: 220-240V 50/60Hz
• Maximum noise level: 34 dB(A)
• IP protection: IP45 (splash resistant)
• Insulation class: II
• Thermal protection: Yes
• Backdraft damper: Removable
• Operating temperature: -5°C to +40°C
• Tube diameter: 118 mm (wall entry 125 mm)
• Dimensions: 187 mm wide x 187 mm high x 164 mm deep
• Maximum/continuous current: 0.12A / 0.09A

Advantages of the SILENT DUAL 200 extractor:

• Autonomous operation: Thanks to its presence and humidity sensors, the extractor self-adjusts without the need for intervention, optimizing ventilation based on the conditions of the space.

• Energy savings and efficiency: The AC motor regulates the flow and energy consumption based on demand, maintaining a balance between performance and energy efficiency.

• Low noise level: With a noise level of only 34 dB(A), this extractor ensures silent operation, ideal for bathrooms where acoustic comfort is required.

The Soler y Palau SILENT DUAL 200 is the perfect solution for those seeking an intelligent, autonomous, and efficient ventilation system. Its ability to learn from the environment and adjust its operation makes it an ideal choice for modern bathrooms where comfort and energy savings are essential.
