GoodWe DNS GW5000D-NS 5 kW Single-phase Solar Inverter

The GoodWe DNS GW5000D-NS single-phase solar inverter is a reliable and efficient solution for residential grid-connected photovoltaic installations. Designed to maximise solar system performance, this inverter offers a nominal output power of 5000 W AC and is equipped with 2 MPPTs (Maximum Power Point Trackers) to optimise energy production by adapting the system's operation to changing solar conditions. With a maximum efficiency of 97.8% and a European efficiency of 97.5%, it guarantees excellent energy performance over the years.

Advanced technology and protection:

The GoodWe GW5000D-NS stands out for its wide MPPT voltage range, varying from 80 V to 550 V, allowing it to adapt to different solar panel configurations and installation conditions. The maximum DC input power reaches 6500 W, making it ideal for residential installations that require efficient management of the generated solar energy.

The inverter incorporates a series of advanced protection elements to ensure system safety and performance. These protections include anti-islanding protection, reverse polarity input protection, insulation resistance detection, and residual current monitoring. Additionally, it also features protection against overloads, short circuits, and overvoltages on the AC output, ensuring stable and safe operation even in adverse conditions.

Compact and efficient design:

The GoodWe GW5000D-NS is designed to deliver robust performance in a compact and lightweight format. Its dimensions (354 mm wide, 433 mm high, and 147 mm deep) and reduced weight make it easy to install, while its IP65 protection rating ensures it can be installed outdoors, being resistant to dust and water. The inverter is cooled by natural convection, eliminating the need for fans and reducing operating noise to less than 25 dB(A), ideal for residential areas where silence is important.

Connectivity and monitoring:

The GoodWe DNS GW5000D-NS inverter is compatible with multiple connectivity options, allowing remote system monitoring via RS485 or WiFi (optional). This enables homeowners to monitor their photovoltaic system's performance in real-time, allowing them to detect any anomalies and ensure maximum utilisation of the generated solar energy. It also features an intuitive user interface with an LCD screen and LEDs, facilitating the display of key parameters such as energy production, system status, and alarms.

Optimal efficiency and performance:

This inverter has a maximum input current of 11 A per MPPT, allowing it to handle solar panel configurations that generate high current levels. It also supports a maximum short circuit current of 13.8 A per string, ensuring system stability in case of overloads. The adjustable power factor between +/- 0.8 allows for optimised use of generated energy, improving overall system performance.

Safety and certifications:

The GoodWe GW5000D-NS inverter complies with strict safety and performance standards, including IEC62109-1&2 and grid connection standards such as VDE0126-1-1, AS4777.2, and UNE 206006. These certifications ensure the inverter not only meets the highest safety standards but is also suitable for use in a wide range of international markets.

Technical specifications:

• Maximum DC input power: 6500 W
• Maximum DC input voltage: 600 V
• MPPT voltage range: 80 V to 550 V
• Nominal DC input voltage: 360 V
• Maximum input current per MPPT: 11 A
• Nominal AC output power: 5000 W
• Nominal AC output voltage: 220/230 V
• AC output frequency: 50/60 Hz
• Maximum AC output current: 22.8 A
• Maximum efficiency: 97.8%
• European efficiency: 97.5%
• Overload and short circuit protection: Integrated
• Protection rating: IP65
• Cooling: Natural convection
• Dimensions: 354 mm x 433 mm x 147 mm
• Weight: 13 kg
• Operating temperature range: -25°C to +60°C
• Noise emission: < 25 dB(A)
• Connectivity: RS485 or optional WiFi
• Night mode self-consumption: < 1.0 W
