Thermor Aéromax VM R290 Heat Pump for DHW, 100 Liters

The Aéromax VM R290 is an aerothermal heat pump designed for the efficient production of domestic hot water (DHW) in small-sized homes. Thanks to its wall-mounted design, it can be installed both indoors and outdoors, occupying minimal space and even allowing placement over a washing machine. Its advanced Smart system optimizes consumption by adapting to the user's lifestyle, while compatibility with photovoltaic installations allows for maximum energy savings.

Maximum Efficiency and Energy Savings

This model belongs to Thermor's Premium series and uses the R290 refrigerant, which improves thermal performance and reduces environmental impact. With an energy rating of A+, the Aéromax VM R290 guarantees high performance even in adverse weather conditions, with a SCOP of 3.34 at 14°C and the ability to operate in an outdoor temperature range of -5°C to 43°C. Additionally, its sound power of only 38 dBA makes it one of the quietest DHW heat pumps on the market.

Advanced Regulation and WiFi Connectivity

The Aéromax VM R290 heat pump incorporates four operating modes to suit different needs:

• Eco: optimizes energy consumption.
• Manual: allows temperature customization.
• Turbo: speeds up DHW production.
• Absence: ideal for periods when the unit is not in use.

Moreover, its integrated WiFi connectivity allows remote management of the unit without the need for additional accessories, ensuring total control over consumption and performance.

Guaranteed Durability and Resistance

Thermor's ACI Hybrid system offers advanced anti-corrosion protection, extending the tank's lifespan regardless of water quality. The vitrified tank with liquid phase coating further enhances its resistance, and the stainless steel resistance prevents scale formation. Additionally, the unit is equipped with a special high-density polyurethane foam insulation that minimizes energy loss.

Easy Installation and Maintenance

The Aéromax VM R290 is designed for easy and versatile installation. Its compact dimensions (576 mm wide, 1054 mm high, and 588 mm deep) make it suitable for small spaces. The front opening allows for quick access to the interior for maintenance tasks, and its adjustable louver system prevents air bypass, ensuring optimal operation. It can be connected to an air duct up to 6 meters with two inlet and outlet elbows.

Technical Specifications

• Capacity: 100 L
• Installation: Wall-mounted
• Refrigerant: R290
• SCOP at 7°C: 2.71 | SCOP at 14°C: 3.34
• Sound power: 38 dBA
• Airflow: 150 m³/h
• Maximum duct length: 50 m
• Power supply: 230 V / 50 Hz
• Heat pump power: 300 W
• Electric support power: 1200 W
• Protection index: ACI Hybrid
• Water temperature: 50°C - 62°C
• Heating time at 14°C: 2 h 47 min
• DHW volume at 40°C in 8 h: 135 L
• Weight: 57 kg

The Thermor Aéromax VM R290 100-liter DHW heat pump is the perfect solution for those seeking efficiency, connectivity, and a compact design without compromising on maximum comfort in domestic hot water production.
