Maldic SENSE V4 Compact Sanitary Grinder for Complete Bathrooms with Wall-Hung Toilet

The Maldic SENSE V4 Compact macerator is specifically designed for the installation of complete bathrooms with suspended toilets, providing an aesthetic and discreet solution by being designed to be embedded within a partition wall. This allows the equipment to be concealed, keeping the bathroom design clean and modern without sacrificing functionality. This model is ideal for bathrooms in homes, commercial premises or any space that requires maximising the available area.

The SENSE V4 Compact features 4 inlets that allow connection to a suspended toilet, washbasin, shower, and bidet, facilitating the discharge of wastewater from the entire bathroom. This makes it an integral and versatile solution for new installations or renovations that demand flexibility and performance.

The discharge capacity of the Maldic SENSE V4 Compact is outstanding, allowing a vertical discharge of up to 8 metres and horizontal up to 80 metres, ensuring its functionality in various installation configurations. Additionally, the macerator includes an elbow with a non-return valve, guaranteeing that the water flow is always in one direction, preventing potential backflows.

The noise level of the equipment is comparable to that of a cistern filling up, ensuring discreet and quiet operation, ideal for use in residential environments. Additionally, a 32 mm discharge pipe is recommended to maximise efficiency, although the pre-equipped elbow accommodates various pipe diameters.

This macerator is equipped with a powerful 450 W motor, capable of handling up to 100 litres per minute of flow, and is manufactured with a stainless steel shaft, ensuring resistance and durability against corrosion. The IPX4 protection rating ensures that the equipment is protected against water splashes, making it suitable for humid environments like bathrooms.

Technical Specifications:

• Reference: 405
• Voltage: 220-240 V
• Frequency: 50 Hz
• Motor consumption: 450 W
• Protection rating: IPX4
• Shaft material: Stainless steel
• Maximum discharge height: 8 m
• Maximum discharge distance: 80 m
• Maximum flow rate: 100 L/min
• Number of inlets: 4 (suspended toilet, washbasin, shower, bidet)
• Maximum liquid temperature: 75 ºC
• Discharge diameter: 23, 28, 32, and 44 mm
• Dimensions: Total width 487 mm, Total depth 153.50 mm, Total height 306 mm

Key Advantages:

• Embedded design: Ideal for modern bathrooms, the equipment is concealed within the partition wall, allowing for a cleaner and more organised aesthetic.
• Versatility: With 4 available inlets, it can collect wastewater from different sources such as a suspended toilet, washbasin, shower, and bidet, covering all the needs of a complete bathroom.
• Efficient discharge: Capable of discharging wastewater up to 8 metres vertically and 80 metres horizontally, allowing flexibility in installation.
• Quiet operation: Its noise level is similar to that of a cistern, ensuring a quiet and discreet environment in the home or commercial premises.

The Maldic SENSE V4 Compact is the perfect solution for those looking to optimise their bathroom space while maintaining a modern and minimalist aesthetic. With efficient performance, a discreet embeddable design, and the ability to discharge waste from multiple sources, this sanitary macerator stands out as a reliable and durable option for any bathroom installation with a suspended toilet.
